17" Idustrial Stainless Steel Industrial Grade Computers 304 For Food Processing Line 1280 * 1024
Features
The Stainless Series Panel PCs combines an elegant design with a rugged build for industrial food, beverage, and pharmaceutical applications. Embrace flexible mounting options, high performance, and IP69K/IP66 standards for ultimate water and dust resistance. The stainless-steel alloy is non-corrosive to meet certain industrial health and safety requirements.
1. 17" TFT LED, resolution 1280 * 1024
2. 10 points capacitive touch screen, high precision, durable, anti-interference.
3. Intel Bay trail j1900 CPU: 2.0GHz, ip69k industrial pc
4. Multi ports for option: VGA/HD-MI/LAN/USB/COM
5. Operating System: Win7/8/10/Linux/Ubuntu
6. DC12V~24V Input,(+9V～36V)wide voltage input optional
| WPC-J017SCC |
| System | CPU | Intel Celeron Quad Core J1900 2.0GHz |
| L2 Cache | 2MB |
| Chipsets | Intel Bay Trail SOC |
| Memory | DDR3L 1333MHz 4GB, Up to 8GB |
| Harddisk | 1 x mSATA 32G SSD / (64G / 128G / 250G / 500G SSD) Optional |
| Graphics | Intel HD Graphics |
| Network | Intel 82583V 1000 Mbps port |
| Audio | Realtek ACL662 Audio controller |
| Operation System | Windows7 / 8 / 10, Linux, Unix, QNX |
| I / O | VGA | 1 x VGA / 1 x HD-MI ( Optional ) |
| LAN | 2 x LAN ( Optional ) |
| USB | 3 x USB2.0 / 1 x USB3.0 ( Optional ) |
| COM | 2 x RS232 ( Optional ) |
| Wireless Network | WiFi + Bluetooth ( Optional ) |
| Other I/O Interface | 1 x Power Switch |
| LCD Panel | Panel Size | 17" Led |
| Resolution | 1280 x 1024 |
| Aspect Ratio | 5:4 |
| Display Brightness | 400 cd/m2 |
| Contrast Ratio | 1000:1 |
| Colors | 16.7M , 90% NTSC |
| Response Time | 30 (Typ.)(Tr+Td) ms |
| Viewing Angle | 88 / 88 / 88 / 88 (CR≥10) ( L / R / U / D ) |
| Touch screen | Touch Screen Type | 10 point capacitive touch |
| Transmittance | >90% |
| Response Time | <5ms |
| Surface Hardness | ≥6H |
| Supply Voltage | 5.0V DC |
| Touch Life | ≧ 3000W |
| Institutional | Material | Stainless Steel SUS04 |
| Color | Polished brushed surface |
| VESA Mounting | VESA: 100 x 100 mm |
| Waterproof Rate | IP66 / IP69K |
| Product Dimension | 393.6 x 326 x 55 mm |
| Cut-out Size | / |
| Packing Size | 500 x 180 x 450 mm |
| Gross Weight | 10.0 KG |
| Power and Environment | Operating Temperature | -10~60°C |
| Storage Temperature | -20~80°C(-22~176°F) |
| Relative Humidity | 5%~95%@40°C, non-condensing |
| Vibration Range | 5-500 Hz, 0.026 G2/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis |
| External Power Supply | AC 100 - 240V~50/60Hz,1.5A |
| Working Voltage | DC 12V~24V / optional(+9V~36V) |
| Power Consumption | ≦30W |
OEM/ODM
1. size from 7''-21.5'' available
2. Processor--Intel J1900/ I3/I5/I7 .....etc lower consumption board
3. Capacitive touch / Resistive touch or without touch
4. 1000nits, 1500nits high brightness for sunlight readable
5. DC 9V～36V wide voltage input
Applications
marine/Sailing boat
medical equipment
humid production equipment
food Industry
chemical manufacturing
outdoor applications
Our Advantage
1. Experience
QYT has more than 10 years rich experience in Industrial Computer/monitor filed.
2. Wide products line
7''-42'' size widely products line, industrial touch panel, embeded computer, lcd monitor, waterproof computer, sunlight readable pc/monitor, android pc...etc.which have excellent work performane.
3. Customization functions
It offers rich of interface to meet csutomers needs.
4.Widely useage environment
QYT computer/monitor which is widly used for kitchen,food industry, boat...etc
